SycoTec easyDrive 4624 - Page 15

EN
15
Subindex 19
Subindex 19 refers to the runtime of the inverter (P25). It is a display value. The value is given in h.
Index
(hex)
Name
Object type
Data type
Access
PDO
mapping
Default
3000:19
h_Umrichter
Variable
Unsigned16
ro
optional,
TPDO only
Subindex 1a
Subindex 1a refers to the runtime of the motor (P26). It is a display value. The value is given in h.
Index
(hex)
Name
Object type
Data type
Access
PDO
mapping
Default
3000:1a
h_Motor
Variable
Unsigned16
ro
optional,
TPDO only
Subindex 1b
Subindex 1b refers to the operating status (P27 – inverter flags) of the inverter.
Bit 10
Bit 9
Bit 8
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
Status
X
X
X
X
X
X
X
X
X
X
1
OPERATION
X
X
X
X
X
X
X
X
X
1
X
WARNING
X
X
X
X
X
X
X
X
1
X
X
FAILURE
X
X
X
X
X
X
X
1
X
X
X
MOTOR ROT
X
X
X
X
X
X
1
X
X
X
X
MOTOR STOP
X
X
X
X
X
1
X
X
X
X
X
OVERLOAD
X
X
X
X
1
X
X
X
X
X
X
SPEED REACHED
X
X
X
1
X
X
X
X
X
X
X
CURRENT LIMIT
X
X
1
X
X
X
X
X
X
X
X
MOTOR TEMP
X
1
X
X
X
X
X
X
X
X
X
I2T
1
X
X
X
X
X
X
X
X
X
X
MOTOR HOLD
NOTE: See also Operating Manual Operating Software SycoDrive for HF Inverters e@syDrive 4624, 4625, 4626.
Index
(hex)
Name
Object type
Data type
Access
PDO
mapping
Default
3000:1b
Inv_Flag
Variable
Unsigned16
ro
optional,
TPDO only
Subindex 1e
Subindex 1e refers to the 1st Error (P30). It is a display value.
Index
(hex)
Name
Object type
Data type
Access
PDO
mapping
Default
3000:1e
stoerung_1
Variable
Unsigned16
ro
optional,
TPDO only
Subindex 1f
Subindex 1f refers to the 2nd Error (P31). It is a display value.
Index
(hex)
Name
Object type
Data type
Access
PDO
mapping
Default
3000:1f
stoerung_2
Variable
Unsigned16
ro
optional,
TPDO only
