Subindex 38
Subindex 38 refers to the DC brake current (P56) for direct current braking with an ASM 3-phase motor.
The value is given from 0…160 in 0.1 A steps; 160 equals 16 A.
Index
(hex)
Name
Object type
Data type
Access
PDO
mapping
Default
3000:38
I_DC_brems
Variable
Unsigned16
rw
no
Subindex 39
Subindex 39 refers to the Holding current (P57). The value is given from 0…30 in 0.1 A steps; 30 equals 3 A.
Index
(hex)
Name
Object type
Data type
Access
PDO
mapping
Default
3000:39
I_DC_halt
Variable
Unsigned16
rw
no
Subindex 3c
Subindex 3c refers to the Voltage 0 (P60) of the V/Hz table. The value is given from 1…650 in 0.1 V steps; 650
equals 65 V.
Index
(hex)
Name
Object type
Data type
Access
PDO
mapping
Default
3000:3c
U0
Variable
Unsigned16
rw
no
Subindex 3d
Subindex 3d refers to the Frequency 1 (P61) of the V/Hz table. The value is given in Hz.
Index
(hex)
Name
Object type
Data type
Access
PDO
mapping
Default
3000:3d
f1
Variable
Unsigned16
rw
no
Subindex 3e
Subindex 3e refers to the Voltage 1 (P62) of the V/Hz table.
The value is given from 1…650 in 0.1 V steps; 650 equals 65 V.
Index
(hex)
Name
Object type
Data type
Access
PDO
mapping
Default
3000:3e
U1
Variable
Unsigned16
rw
no
Subindex 3f
Subindex 3f refers to the Frequency 2 (P63) of the V/Hz table. The value is given in Hz.
Index
(hex)
Name
Object type
Data type
Access
PDO
mapping
Default
3000:3f
f2
Variable
Unsigned16
rw
no
Subindex 40
Subindex 40 refers to the Voltage 2 (P64) of the V/Hz table.
The value is given from 1…650 in 0.1 V steps; 650 equals 65 V.
Index
(hex)
Name
Object type
Data type
Access
PDO
mapping
Default
3000:40
U2
Variable
Unsigned16
rw
no
Subindex 41
Subindex 41 refers to the Frequency 3 (P65) of the V/Hz table. The value is given in Hz.
Index
(hex)
Name
Object type
Data type
Access
PDO
mapping
Default
3000:41
f3
Variable
Unsigned16
rw
no
