SycoTec easyDrive 4624 - Page 21

EN
21
Subindex 53
Subindex 53 refers to the speed control TV (P83). The value is given in ms.
Index
(hex)
Name
Object type
Data type
Access
PDO
mapping
Default
3000:53
N-Reg-t_v
Variable
Unsigned16
rw
no
Subindex 54
Subindex 54 refers to the Speed control TF (P84). The value is given in ms.
Index
(hex)
Name
Object type
Data type
Access
PDO
mapping
Default
3000:54
N-Reg-t_fill
Variable
Unsigned16
rw
no
Subindex 55
Subindex 55 refers to the Temperature monitoring (P85).
Value
Selection inverter
0000
hex
Off
802a
hex
NTC
802b
hex
PTC
802c
hex
PT1000
802d
hex
KTY84
NOTE: See also Operating Manual Operating Software SycoDrive for HF Inverters e@syDrive 4624, 4625, 4626.
Index
(hex)
Name
Object type
Data type
Access
PDO
mapping
Default
3000:55
Motorschutz
Variable
Unsigned16
rw
no
Subindex 56
Subindex 56 refers to the Resistance value (P86) of the temperature monitoring. The value is given in Ohm.
Index
(hex)
Name
Object type
Data type
Access
PDO
mapping
Default
3000:56
Sensorwert
Variable
Unsigned16
rw
no
Subindex 5a
Subindex 5a refers to the Motor type (P90).
Value
Selection inverter
8001
hex
No motor
8002
hex
ASM 3-phase
8003
hex
PMSM
NOTE: See also Operating Manual Operating Software SycoDrive for HF Inverters e@syDrive 4624, 4625, 4626.
Index
(hex)
Name
Object type
Data type
Access
PDO
mapping
Default
3000:5a
Motortyp
Variable
Unsigned16
rw
no
Subindex 5b
Subindex 5b refers to the Rated frequency (P91). The value is given in Hz.
Index
(hex)
Name
Object type
Data type
Access
PDO
mapping
Default
3000:5b
f_mot_nenn
Variable
Unsigned16
rw
no
