Subindex 5c
Subindex 5c referst to the Rated voltage (P92). The value is given from 0…650 in 0.1 V steps; 650 equals 65 V.
Index
(hex)
Name
Object type
Data type
Access
PDO
mapping
Default
3000:5c
U_mot_nenn
Variable
Unsigned16
rw
no
Subindex 5d
Subindex 5d refers to the Rated current (P93). The value is given from 5…160 in 0.1 A steps; 160 equals 16 A.
Index
(hex)
Name
Object type
Data type
Access
PDO
mapping
Default
3000:5d
I_mot_nenn
Variable
Unsigned16
rw
no
Subindex 5e
Subindex 5e refers to cos_phi (P94). The value is given in %.
Index
(hex)
Name
Object type
Data type
Access
PDO
mapping
Default
3000:5e
cos_phi
Variable
Unsigned16
rw
no
Subindex 60
Subindex 60 refers to the Number of pole pairs (P96).
Index
(hex)
Name
Object type
Data type
Access
PDO
mapping
Default
3000:60
mot_polpaarzahl
Variable
Unsigned16
rw
no
Subindex 61
Subindex 61 refers to the Input current (P97). It is a display value. The value is given in 0.1 A steps.
Index
(hex)
Name
Object type
Data type
Access
PDO
mapping
Default
3000:61
Nsoll_I_in
Variable
Unsigned16
ro
no
Subindex 62
Subindex 62 refers to the Input voltage (P98). It is a display value. The value is given in 0.1 V steps.
Index
(hex)
Name
Object type
Data type
Access
PDO
mapping
Default
3000:62
Nsoll_U_in
Variable
Unsigned16
ro
no
Subindex 63
Subindex 63 refers to the Temperature at heat sink (P99). It is a display value. The value is given in 0.1 °C steps.
Index
(hex)
Name
Object type
Data type
Access
PDO
mapping
Default
3000:63
Temp_KK
Variable
Unsigned16
ro
no
Subindex 64
Subindex 64 refers to the DC link voltage (input) (P100). It is a display value. The value is given in 0.1 V steps.
Index
(hex)
Name
Object type
Data type
Access
PDO
mapping
Default
3000:64
Uzk_input
Variable
Unsigned16
ro
no
