Subindex 65
Subindex 65 refers to the diagnosis function of the relays and LEDs in the Actuator / Sensor Test (P101).
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
Output
X
X
X
X
X
X
X
1
Relay 1
X
X
X
X
X
X
1
X
Relay 2
X
X
X
X
X
1
X
X
LED Fault
X
X
X
X
1
X
X
X
LED Operation
X
X
X
1
X
X
X
X
Invert Relay 1
X
X
1
X
X
X
X
X
Invert Relay 2
X
1
X
X
X
X
X
X
Invert LED Fault
1
X
X
X
X
X
X
X
Invert LED Operation
NOTE: See also Operating Manual Operating Software SycoDrive for HF Inverters e@syDrive 4624, 4625, 4626.
Index
(hex)
Name
Object type
Data type
Access
PDO
mapping
Default
3000:65
diag1
Variable
Unsigned16
ro
no
Subindex 66
Subindex 66 refers to the diagnosis function of the digital inputs, the PLC input and the motor temperature
monitoring in the Actuator / Sensor Test (P102).
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
Input
X
X
X
X
X
X
X
1
DIN 1
X
X
X
X
X
X
1
X
DIN 2
X
X
X
X
X
1
X
X
DIN 3
X
X
X
X
1
X
X
X
DIN 4
X
X
X
1
X
X
X
X
DIN 5
X
X
1
X
X
X
X
X
DIN 6
X
1
X
X
X
X
X
X
Temperature monitoring (motor)
1
X
X
X
X
X
X
X
PLC input
NOTE: See also Operating Manual Operating Software SycoDrive for HF Inverters e@syDrive 4624, 4625, 4626.
Index
(hex)
Name
Object type
Data type
Access
PDO
mapping
Default
3000:66
diag2
Variable
Unsigned16
ro
no
Subindex 68
Subindex 68 refers to the Fixed frequency 1 (P104). The value is given in Hz.
Index
(hex)
Name
Object type
Data type
Access
PDO
mapping
Default
3000:68
fix_freq_1
Variable
Unsigned16
rw
no
Subindex 69
Subindex 69 refers to the Fixed frequency 2 (P105). The value is given in Hz.
Index
(hex)
Name
Object type
Data type
Access
PDO
mapping
Default
3000:69
fix_freq_2
Variable
Unsigned16
rw
no
Subindex 6a
Subindex 6a refers to the Fixed frequency 3 (P106). The value is given in Hz.
Index
(hex)
Name
Object type
Data type
Access
PDO
mapping
Default
3000:6a
fix_freq_3
Variable
Unsigned16
rw
no
