EN
25
Subindex 72
Subindex 72 refers to DIN5 (P114).
Value
Selection inverter
0000
hex
Off
803e
hex
Reset
803f
hex
Speed direction
8040
hex
Motor code bit 2
8041
hex
Fixed frequency bit 1
8042
hex
Parameter import
NOTE: See also Operating Manual Operating Software SycoDrive for HF Inverters e@syDrive 4624, 4625, 4626.
Index
(hex)
Name
Object type
Data type
Access
PDO
mapping
Default
3000:72
dig_in_5
Variable
Unsigned16
rw
no
Subindex 73
Subindex 73 refers to DIN6 (P115).
Value
Selection inverter
0000
hex
Off
803e
hex
Reset
803f
hex
Speed direction
8040
hex
Motor code bit 3
8041
hex
Fixed frequency bit 0
8043
hex
Parameter export
NOTE: See also Operating Manual Operating Software SycoDrive for HF Inverters e@syDrive 4624, 4625, 4626.
Index
(hex)
Name
Object type
Data type
Access
PDO
mapping
Default
3000:73
dig_in_6
Variable
Unsigned16
rw
no
Subindex 74
Subindex 74 refers to the PLC input (P116).
Value
Selection inverter
0000
hex
Off
803b
hex
Start/Stop
NOTE: See also Operating Manual Operating Software SycoDrive for HF Inverters e@syDrive 4624, 4625, 4626.
Index
(hex)
Name
Object type
Data type
Access
PDO
mapping
Default
3000:74
Start_In
Variable
Unsigned16
rw
no
