SycoTec easyDrive 4624 - Page 26

EN
26
Subindex 78
Subindex 78 refers to Relay 1 (P120).
Value
Selection inverter
0000
hex
Off
804a
hex
Operation
804b
hex
Warning
804c
hex
Failure
804d
hex
Overload
804e
hex
Nominal speed reached
804f
hex
Current limit
8050
hex
Motor temperature
8051
hex
Motor downtime
8052
hex
Motor runs
8053
hex
I²t warning
8054
hex
Holding operation
NOTE: See also Operating Manual Operating Software SycoDrive for HF Inverters e@syDrive 4624, 4625, 4626.
Index
(hex)
Name
Object type
Data type
Access
PDO
mapping
Default
3000:78
relais_1
Variable
Unsigned16
rw
no
Subindex 79
Subindex 79 refers to Relay 2 (P121).
Value
Selection inverter
0000
hex
Off
804a
hex
Operation
804b
hex
Warning
804c
hex
Failure
804d
hex
Overload
804e
hex
Nominal speed reached
804f
hex
Current limit
8050
hex
Motor temperature
8051
hex
Motor downtime
8052
hex
Motor runs
8053
hex
I²t warning
8054
hex
Holding operation
NOTE: See also Operating Manual Operating Software SycoDrive for HF Inverters e@syDrive 4624, 4625, 4626.
Index
(hex)
Name
Object type
Data type
Access
PDO
mapping
Default
3000:79
relais_2
Variable
Unsigned16
rw
no
Subindex 7d
Subindex 7d refers to the Warning current (P125) of the relays.
The value is given from 4…120 in 0.1 A steps; 120 equals 12 A.
Index
(hex)
Name
Object type
Data type
Access
PDO
mapping
Default
3000:7d
I_warn
Variable
Unsigned16
rw
No
