Subindex 81
Subindex 81 refers to the source for AIN (P129).
Value
Selection inverter
805a
hex
U (0…10 V)
805b
hex
I (0…20 mA)
NOTE: See also Operating Manual Operating Software SycoDrive for HF Inverters e@syDrive 4624, 4625, 4626.
Index
(hex)
Name
Object type
Data type
Access
PDO
mapping
Default
3000:81
analog_in
Variable
Unsigned16
rw
no
Subindex 82
Subindex 82 refers to the CAN node ID (P130).
Index
(hex)
Name
Object type
Data type
Access
PDO
mapping
Default
3000:82
can_node_id
Variable
Unsigned16
rw
no
Subindex 87
Subindex 87 refers to the Minimum frequency (P135) of the analog input. The value is given in Hz.
Index
(hex)
Name
Object type
Data type
Access
PDO
mapping
Default
3000:87
f_fern_min
Variable
Unsigned16
rw
no
Subindex 88
Subindex 88 refers to the Maximum frequency (P136) of the analog input. The value is given in Hz.
Index
(hex)
Name
Object type
Data type
Access
PDO
mapping
Default
3000:88
f_fern_max
Variable
Unsigned16
rw
no
Subindex 89
Subindex 89 refers to the Maximum voltage (P137) of the analog input.
The value is given from 1…100 in 0.1 V steps; 100 equals 10 V.
Index
(hex)
Name
Object type
Data type
Access
PDO-
mapping
Default
3000:89
AIN_Vmax
Variable
Unsigned16
rw
no
Subindex 8a
Subindex 8a refers to the Maximum current (P138) of the analog input.
The value is given from 4…200 in 0.1 mA steps; 200 equals 20 mA.
Index
(hex)
Name
Object type
Data type
Access
PDO
mapping
Default
3000:8a
AIN_Imax
Variable
Unsigned16
rw
no
Subindex 8c
Subindex 8c refers to the Input for start (P140). It describes from which source the frequency inverter
receives the start / stop command.
Value
Selection inverter
805c
hex
Digital inputs
805d
hex
SycoDrive
805e
hex
CAN
NOTE: See also Operating Manual Operating Software SycoDrive for HF Inverters e@syDrive 4624, 4625, 4626.
Index
(hex)
Name
Object type
Data type
Access
PDO
mapping
Default
3000:8c
input_start
Variable
Unsigned16
rw
no
