3. Lubrication System
3-1
Lubrication System Diagram ················3-1
Precautions In Operation ······················3-2
Lubricant·················································3-2
Trouble Shooting ···································3-2
Oil Pump Removal································· 3-3
Oil Pump Installation····························· 3-3
Oil Pump/Oil Tube Air Bleeding ··········· 3-4
Oil Tank··················································· 3-5
Lubrication System Diagram
Oil pump
Oil output tube
Oil tube
Oil lever switch
Oil tank
