SYM 16. ELECTRICAL EQUIPMENT
16-3
Specification
Charging System
Item Specification
Type YTX7A-BS
Capacity 12V6Ah
Battery
Charging rate
0.7A / 5~10 hours (standard), 3A / 1 hour (fast
charging)
Leak current < 1 mA
Charging current 2.1 A / 5000 rpm ↑
Control voltage in charging 14.0~15.0 V / 5000 rpm
Ignition System
Item Specification
Model NGK BR8HSA (Recommended)
Spark plug
Gap 0.6~0.7 mm
Primary coil
0.19~0.23 Ω
Ignition coil and
resistance
Secondary coil
2.8~3.4 KΩ
Ignition timing “F” mark 13°BTDC / 1700 rpm
