Sym JOYRIDE 125 Service Manual

7. Cylinder Head / Valve
7-4
Cylinder Head Removal
Remove cushion and body center cover.
Remove the clamp strip bolt of carburetor, and
disconnect vacuum tube from the carburetor
insulator.
Remove 1 bolt of thermostat and then remove
the thermostat.
Remove the side cover mounting blot of cylinder
head, and then take out the side cover.
Remove hole cap for the adjustment bolt of cam
chain tensioner, and then loosen the tensioner
by turning a flat-driver in C.W direction.
Remove cam sprocket bolt and then remove the
sprocket by prying chain out.
Clamp strip
Vacuum tube
Mounting bolt
Thermostat bolt
Hole cap of adjustment bolt
To this chapter contents

Sym JOYRIDE 125 Specifications

General

Displacement	124.6 cc
Fuel System	Electronic Fuel Injection
Transmission	CVT
Front Suspension	Telescopic fork
Rear Suspension	Unit Swing
Front Brake	Disc
Rear Brake	Drum
Length	1900 mm
Engine Type	4-stroke
Cooling System	Air-cooled
