Sym JOYRIDE 125 Service Manual

9. V-Belt Drive System
9-1
Mechanism Diagram ............................9-1 Drive Belt............................................9-5
Precautions in Operation ....................9-2 Drive face............................................9-6
Troubleshooting...................................9-2 Clutch outer / Driven pulley ..............9-10
Left Crankcase Cover ..........................9-3
Mechanism Diagram
5.0~6.0 kgf-m
5.0~6.0 kgf-m
3.5~4.5 kgf-m
Homepage
Contents
9

Sym JOYRIDE 125 Specifications

General

Displacement	124.6 cc
Fuel System	Electronic Fuel Injection
Transmission	CVT
Front Suspension	Telescopic fork
Rear Suspension	Unit Swing
Front Brake	Disc
Rear Brake	Drum
Length	1900 mm
Engine Type	4-stroke
Cooling System	Air-cooled
