Symbol P370 - Page 55

3-25
Operation
Figure 3-4. P370 ALR Scanner - Decode Zone
0 in.
0 cm
35 in.
88.9 cm
70 in.
177.8 cm
105 in.
266.7 cm
140 in.
355.6 cm
175 in.
444.5 cm
210 in.
533.4 cm
245 in.
622.3 cm
280 in.
711.2 cm
315 in.
800.1 cm
Distance From Front Of Scanner
15.0 in.
38.1 cm
15.0 in.
38.1 cm
10 in.
25.4 cm
10 in.
25.4 cm
5 in.
12.7 cm
5 in.
12.7 cm
0 in.
0 cm
Width
Field
Of
100% UPC
15 Mil
40 Mil
55 Mil
70 Mil Reflective
100 Mil Reflective
350 in.
889.0 cm
385 in.
977.9 cm
20.0 in.
50.8 cm
20.0 in.
50.4 cm
