ATS-6511A/B/C Users Guide
64
1 MHz Module (4395B-1)
This module provides four 1 MHz outputs. The module also monitors each output for levels
below approximately 10 dBm, after which an alarm is raised.
Characteristic Description
Number of outputs Four
Output connectors BNC(F)
Impedance 50 Ω
Amplitude +13dbm +/- 2dBm
Signal Sine Wave
Harmonics < -40dBc
Phase Noise ATS 6511C
0.1Hz -100 dBc/Hz
1 Hz -130 dBc/Hz
10 Hz -145 dBc/Hz
100 Hz -154 dBc/Hz
1 kHz -158 dBc/Hz
10 kHz -160 dBc/Hz
100 kHz -160 dBc/Hz
1 MHz -160 dBc/Hz
Amplitude Modulated (AM) IRIG Module (4387A, 4387A-6V)
Characteristic Description
Number of outputs Four
Output connectors BNC(F)
Impedance 50 Ω
Amplitude into 50 Ω 3 Vpp, 6 Vpp(4387A-6V)
Modulation Ratio 3:1
IRIG types Default - B120
Supported Types A130, A133, A137, B120, B123, B127, E 111, E112, E121, E122, E127,
G141, G142, G147, H111, H112, H121, H122, H127 or NASA36
