Page #71 background imageLoading...
Page #71 background image
DOC 6511_Release K
ATS-6511A/B/C Users Guide
65
L-Band Output Module (4399A)
Characteristic
Description
Number of outputs Four RF, One 1 PPS
Output connectors SMA(F)
Impedance 50
RF Amplitude into 50
-20 dBm
RF output frequency
range
900 MHz – 1175 MHz, 1225 MHz – 1575 MHz, and 1625 MHz – 1750 MHz
1 PPS output
- Pulse Width 100 µs
- Rise Time < 15 ns
- Jitter <200 ps RMS
- Skew to other 1
PPS outputs
< ±2 ns
Communications DB-9 Female connector, See section 2.4.2.3 for details and commands
AC Power Supply (4385A)
100–240 V AC, 50-60 Hz, ~.75A
Power Mains Fuse AC Input: Two 250 V~1 A T (Time delay) 5 x 20 mm
AC Power Supply (4385B)
100–240 V AC, 50-60 Hz, ~.75A, Power Factor Corrected to 0.97
Power Mains Fuse AC Input: Two 250 V~1 A T (Time delay) 5 x 20 mm
DC Power Supply (4886A)
–48 VDC (SELV type) (18-60 V), Power Inlet Type, DC input Mates with 3 pin Amp Part#: 1-350346-0
connector with female sockets Amp Part# 925661-1
Power Supply Cord Set, DC input Minimum 1.5 mm² (14 AWG) with a 15A fuse or circuit breaker. A 20A
circuit breaker may be used if the external wiring is jacketed 14 AWG, with maximum length of 20 feet.
DC Input: Two 250 V~1.6 A T (Time delay) 5 x 20 mm
Power Consumption: 52W (fully loaded chassis).
