1) Turn shower handle counterclock-
wise approximately 1/4 turn to put
valve in cold position.
Operation (Temperature Control)
2) Turn shower handle counterclock-
wise approximately 1/2 turn to put
valve in warm position.
3) Turn shower handle counterclock-
wise approximately 3/4 turn to put
valve in hot position.
2) Turn volume control handle right for low ow.
1) Turn volume control handle left for high ow.
Operation (Diverter Control)
1) Turn diverter handle left for tub spout operation. 2) Turn diverter handle right for showerhead operation.
Operation (Volume Control)
Troubleshooting Chart
Problem Cause Solution
Finish is spotting.
Elements in water supply may cause
water staining on nish.
Clean nished trim area with a soft
cloth using mild soap and water or a
non-abrasive cleaner and then quickly
rinse with water.
To Next Page
