Synesso S Series User Manual

33
SYNESSO
Annual Warranty Checklist
S Series Machines
To qualify for the Synesso 2 and 5 year warranty, this checklist must be returned to Synesso within 30 days of 1 year in service.
 Replace portalter gaskets
8.5mm 1.3441 (standard size)
9.0mm 1.3430 (for older handles with worn ears)
 Replace group diuser screens
Synesso reinforced screen 1.3292
 Inspect portalter baskets for wear or damage. Replace if necessary
14 gram basket 1.7000
18 gram basket 1.7090
21 gram basket 1.7170
 Rebuild or replace steam valves. Clean and lubricate wand pivot ball and pusher face
Rebuild kit 1.7320
Complete valve 1.4501
 Remove and clean steam ps
 Remove side and splash panels, inspect tanks, copper tubes, and all ngs for leaks
 Inspect and replace all ruby ow restrictors and brew valves
Ruby jet replacement kit (0.6mm) 1.3191
Brew valve 1.2460
 Check ow rate at each brew group. 2oz water in 6-8 seconds
 Test consistency and accuracy of volumetrics across all groups
 Check that expansion valve does not leak at 9bar. 11-12 bar is the factory standard seng
Expansion valve 1.4070
 Check line and pump pressures
 Replace steam tank vacuum breaker
Vacuum breaker 1.4265
 Inspect steam tank pressure relief valve (dark spots may indicate leaking). Replace if signs of leaking.
Pressure relief valve 1.4100
 Depressurize steam and brew systems, check that gauges return to zero. Replace if not accurate.
0-60psi steam gauge 1.4083
0-300psi brew gauge 1.3373
 Remove and inspect level probes. Clean scale build up if necessary
Upper level probe (ll probe) 1.4111
Lower (safety) probe 1.4112
 Inspect drain hose for clogs or leaks
 Check element gaskets for signs of leaking, ghten if needed
 Test handheld controller for proper operaon. All buons react as normal
 Test steam tank element set points. Cycle each loop of element
Authorized Technician Signature and Date _________________________________
Customer Name: _____________
Machine Model: ______________
Serial Number: _______________
