PCIe IP Prototyping Kit Installation Guide Setting Up Hardware Components
DesignWare PCIe Gen4 Endpoint Controller on HAPS-80, E16 PHY, PCIe connection for PC (E825-0)
1 HW0352-000 HAPS-80 S26 (-2) High-Performance ASIC Prototyping System HAPS-80
1 DWC_PHY_E16_P
CIe_Gen4
PHY Board Synopsys E16 PHY Board (PCIe Gen4 PHY)
1 8KH2-0723-0250
a
3M
TM
PCIe x8
Extender
Twin Axial Cable Assembly or PCIe x8 extender card
applications
1 3052113 SD Card TRANSCEND TS2GSDC CARD
DesignWare PCIe Endpoint Controller on HAPS-80, C10 PHY, PCIe connection for PC (E025-0)
1 8KH2-0723-0250
a
3M
TM
PCIe x8 Extender Twin Axial Cable Assembly or PCIe x8 extender card
applications
1 HW0352-000 HAPS-80 S26 (-2) High-Performance ASIC Prototyping System HAPS-80
1 DWC_PHY_C10_P
Cle_Gen3
PHY Board Synopsys C10 PHY Board (PCIe Gen3 PHY)
1 3052113 SD Card TRANSCEND TS2GSDC CARD
DesignWare PCIe Root Complex Controller on HAPS-80, C10 PHY, AXI tunnel to ARC SDP (E026-0)
1 HW0352-000 HAPS-80 S26 (-2) High-Performance ASIC Prototyping System HAPS-80
1 DWC_PHY_C10_P
Cle_Gen3
PHY Board Synopsys C10 PHY Board (PCIe Gen3 PHY)
1 8KH2-0723-0250
a
3M
TM
PCIe x8 Extender Twin Axial Cable Assembly or PCIe x8 extender card
applications
1 HW0071-0 ARC AXS101 SDP DesignWare ARC AXS 101 Software Development Platform
2 HW0039-0 CON_CABLE_25_HT3 HT3 Cables
1 N/A PCIe Backplane Rev. C PCIe Root Complex - Endpoint Backplane
2 3052113 SD Card TRANSCEND TS2GSDC CARD
DesignWare PCIe Gen3 Endpoint Controller on HAPS-80, Xilinx Gen3 PHY, with PCIe connection for PC (C046-0)
1 HW0352-000 HAPS-80 S26 (-2) High-Performance ASIC Prototyping System HAPS-80
1 3052113 SD Card TRANSCEND TS2GSDC CARD
Table 1-2 PCIe IP Prototyping Kit Recommended Components and Part Numbers (Continued)
Quantity Part Number Item Description
