Setting Up Hardware Components PCIe IP Prototyping Kit Installation Guide
1 HW0270-0 PCIE x4 Gen3 kit
b
The PCIE x4 Gen3 kit includes the following components:
■
PCIE-4 MGB – Four lane PCI Express card with MGB
connection
■
PCIE-4 PC – Four lane PCI Express card with PC
connection
■
PCIE-4 Cable – Four lane connection cable
DesignWare PCIe Gen3 Root Complex Controller on HAPS-80, Xilinx Gen3 PHY, AXI tunnel to ARC SDP (E027-0)
1 HW0071-0 ARC AXS101 SDP DesignWare ARC AXS 101 Software Development Platform
1 HW0352-000 HAPS-80 S26 (-2) High-Performance ASIC Prototyping System HAPS-80
2 3052113 SD Card TRANSCEND TS2GSDC CARD
1 HW0270-0 PCIE x4 Gen3 kit The PCIE x4 Gen3 kit includes the following components:
■
PCIE-4 MGB – Four lane PCI Express card with MGB
connection
■
PCIE-4 PC – Four lane PCI Express card with PC
connection
■
PCIE-4 Cable – Four lane connection cable
2 HW0039-0 CON_CABLE_25_HT3 HT3 Cables
1 N/A PCIe Backplane Rev. C PCIe Root Complex - Endpoint Backplane
DesignWare PCIe Gen5 Root Complex Controller on HAPS-80, E32 PHY, AXI tunnel to ARC HS (E828-0)
1 HW0352-000 HAPS-80 S26 (-2) High Performance ASIC Prototyping System (HAPS-80)
1 DWC_PHY_E32_P
CIe_Gen5
PHY Board Synopsys E32 PHY Board (PCIe Gen5 PHY)
1 HW0469-000 ARC HSDK DW ARC HSDK Development Kit
1 3052113 SD card TRANSCEND TS2GSDC CARD
1 SDSQUAR-064G-
GN
Micro SD Micro SD card
DesignWare PCIe Gen5 Endpoint on HAPS-80, E32 PHY, with PCIe connection to PC (E827-0)
1 HW0352-000 HAPS-80 S26 (-2) High Performance ASIC Prototyping System (HAPS-80)
1 DWC_PHY_E32_P
CIe_Gen5
PHY Board Synopsys E32 PHY Board (PCIe Gen5 PHY)
8 HW0240-000 H_EXT_CABLE40_HT
3
HT3 cables
1 3052113 SD card TRANSCEND TS2GSDC CARD
Table 1-2 PCIe IP Prototyping Kit Recommended Components and Part Numbers (Continued)
Quantity Part Number Item Description
