operation

SYNRAD OEM v40 Operator’s Manual Version 4

OEM controls and indicators

OEM v40 side panel

(SAB models)

Figure 3-5 OEM v40 side panel controls and indicators

DB-9 connector – provides a Shutter Switch input as well as auxiliary +5 and +24 VDC outputs. See

DB-9 connections in the Technical Reference chapter for connection details.

(Air-Cooled v40 OEM Shown)
