Synrad p250 User Manual

5 p250 Laser Quick Start Guide Version 3.1
p250 Quick Start Guide
250
6. Before mounting the laser to the rail, ensure the aperture seal is removed.
7. Locate the Mounting Hardware ( ) path enclosure tube, marking head & laser
hardware.
Remove the
aperture seal.
Failure to
remove can
damage the
laser!
Path enclosure tube.
Four (4) nuts and Eye bolts.
Eight (8) Long laser mounting bolts.
Four (4) Triangle bolts.
Two (2) Pegs.
Eight (8) Marking Head Mounting bolts.
Twelve (12) laser mounting bolts.
Mounting (Continued):
