Description
|
3
Warning
When opening the transport packaging, there is a risk of damage from sharp edges, nails, staples,
splinters etc.
♦ Unpack the fan carefully.
♦ Check the fan for obvious transport damage.
♦ Only remove the packaging shortly before assembly.
♦ Wear protective equipment during all work in the vicinity of the fan, details see 2.2 Personal protective
equipment, page 2.
4.3 Transport
4.3.1 Safety information
Warning: Electrical or mechanical hazards due to fire,
moisture, short circuit or malfunction.
♦ Never transport the fan by the connecting wire,
terminal box, impeller, protection grille, inlet cone or
silencer.
♦ In open transport, please make sure that no water can
penetrate into the motor or other sensitive parts.
♦ We recommend transporting the fan to the
installation site in the original packaging.
Caution: If transported without care during loading and
unloading, the fan may be damaged.
♦ Load and unload the fan carefully.
♦ Use hoisting equipment that is suitable for the weight
to be hoisted.
♦ Observe the transportation arrows on the packaging.
♦ Use the fan packaging exclusively as transport
protection and not as a lifting aid.
4.4 Storage
Safety information
Warning: Risk of injury and damage to the fan.
♦ Do not stack the fans on top of one another.
♦ Do not use transport packaging as hoisting aids.
♦ Use hoisting equipment that is suitable for the weight
to be hoisted.
Preconditions
♦ Store the devices in a clean, dry and vibration-free
environment.
♦ Storage temperature should be between –20°C and
60°C.
Storage more than 3 months
♦ Turn the impeller at least 10 revolutions once a
month.
♦ Please ensure that the impeller is at a different
position afterwards.
Storage more than 12 months
♦ We recommend an inspection by the after-sales
service of Systemair before commissioning.
5 Description
5.1 General
• The fan conveys air in an axial direction from the intake side via the electric motor to the outlet side. (except AXCBF).
• The electrical connection is made through a terminal box installed on the outside of the housing (except AXCBF).
Sensors (optional)
Sensors can be connected to the fan to monitor the roller bearings and for vibration monitoring.
Standstill heating (optional)
The standstill heating starts when the motor switches off and vice versa.
