Geniox Air Handling Unit - User Manual | 3060386
4-5 | ERW maintenance
d
2
=
0" (STA RT UP)
d
2
'
=
WHEEL TOLERANCE
d
2
WHEEL MEDIA
IR0005
TOO
CLOSE
CORRECT
WRONG
WRONG
TOO
FAR
PERIPHERAL S-TYPE SEAL
TheS-typelabyrinthperipheralsealisanon-contactsealxedtothefaceplateoftheunit.Thesealoverlapsinsidetherotorcasingfor
increaseairtightness.Itisfactoryinstalledandadjusted.Nosealadjustmentisrequiredintheeld.
LOW FRICTION SIDE & CENTER
Thelowfrictionsideandcentersealarecontactsealsxedtothewheelframe.Themiddlesealsarelocatedbehindthepillowblock
bearings. The side seals are installed on the side of the rotor, along the depth dimension. They are factory installed and adjusted. No seal
adjustmentisrequiredintheeld.
