Geniox Air Handling Unit - User Manual | 3060386
14 | Instruction for unloading on the site as well as installation and connection
Caution
It is strictly forbidden to lift a section under the top of the section. The plastic corners and brackets are not at all
reinforced for lifting the unit under the top. There is serious risk of injury and damage to property from heavy
components falling.
Pull sections together with a strap. We recommend a ratchet tie
downstrapbecausethistypedoesnotdamagetheframeproles
of the unit. An example of strap is shown to the right. Note! Do
not place the strap on the vertical proles because the plastic
corners and the proles are not at all reinforced for the heavy
load and stress that is created by the tensioner. To avoid any
load and stress on the plastic corners the strap must be carefully
placed on the bottom proles of the unit when sections are
pulled together.
G.2.4 Installation on the site of unit sections
