3060386 | Geniox Air Handling Unit - User Manual
Designation Tag Option Description
1 Series GNX Geniox Unit
2 Unit Size
10 Coil Size = 10 sq.ft, nominal 5,000 cfm
12 Coil Size = 12 sq.ft, nominal 6,000 cfm
15 Coil Size = 15 sq.ft, nominal 7,500 cfm
20 Coil Size = 20 sq.ft, nominal 10,000 cfm
25 Coil Size = 25 sq.ft, nominal 12,500 cfm
30 Coil Size = 30 sq.ft, nominal 15,000 cfm
35 Coil Size = 35 sq.ft, nominal 17,500 cfm
40 Coil Size = 40 sq.ft, nominal 20,000 cfm
3 Location
I Indoor
O Outdoor
4 Access
L Left hand side
R Right hand side
5 Structure
SH Single Height H=W/2,One Airstream
DH Double Height H=W/, Two Airstreams
6 Pre- Heater
0 No Pre-heater
1 Electrical Element Pre-heater
2 Hot Water Coil Pre-heater
7 Energy Recovery
0 No Energy Recovery (NE)
1 Sensible Rotational Wheel (RS)
2 Enthalpy Rotational Wheel (RE)
3 Sensible Plate Heat Exchanger (PS)
4 Enthalpy Membrane Exchanger (PE)
8 Fan Type
EC Plug-EC Fan
AC Plug-AC Fan
9 Fan Quantity
1 Number of fans per airstream (Single fan)
2 Number of fans per airstream (Fan array)
3 Number of fans per airstream (Fan array)
4 Number of fans per airstream (Fan array)
10 Cooling Type
CW Cooling - Chilled Water Coil
DX Cooling - DX Coil
VF Cooling -VRF
NC No Cooling
11 Heating Type
HW Heating - Hot Water Coil
EH Heating- Electrical Heater
VF Heating - VRF
NH No Heating
12 Voltage
1 208 Volt/3-phase/60Hz
2 460 Volt/3-phase/60Hz
3 575 Volt/3-phase/60Hz
B Nomenclature
This manual covers Systemair Geniox Air Handling Units, sizes 10 thru 40.
AHU Designation 12 345 6789 1011 12
Nomenclature | 3
