G.2.5 Joining the AHU sections
Position the unit sectional modules directly opposite each other
Ensurethattheinternalfactory-ttedrubbersealingisundamaged
Section Clamps (Shipped loose) must then be installed using the table below for placement.
Side Mount Rule** Number and positioning
Service/Access Inside If height < 23-5/8” (600 mm) 1 in the middle
Ifheight≥23-5/8”(600mm) 2 pcs. 6” (150 mm) away from edge **
Ifheight≥47-1/4”(1200mm) 1 more in the middle
Back Outside If height < 23-5/8” (600 mm) 1 in the middle
If height > 23-5/8” (600 mm) 2 pcs. 6” (150 mm) away from edge
Ifheight≥47-1/4”(1200mm) 1 more in the middle
Top & Bottom Inside if unit width < 59” (1500 mm) N/A
if unit width > 59” (1500 mm) 1 in the middle
**Distances used apply to each air stream. So a Double High unit that is 55-1/8” (1400 mm) high will count as 2
streams 27-1/2” (700 mm) each.
16 | Instruction for unloading on the site as well as installation and connection
Pressthesectionstogethersothattherubberprolesareatandtheframesofthetwosectionsarejoined.Strapwithtensioneris
suitable for pressing the sections together. Note: Do not place the strap on the vertical proles because the plastic corners and the
proles are not reinforced for the heavy load and stress created by the tensioner. To avoid any load and stress on the plastic corners
and the proles the strap must be carefully placed on the bottom proles of the unit.
