Fig.4Rotordrivebelt
5.7.1Heatexchangermounted
1.Stoptheunitbydisconnectingthemains.
2.Openthefronthatch.
3.Removethebrokendrivebelt.
4.Usetapetoattachthedrivebelttotherotatingheatexchanger,androtatetheexchangerbyhand
togetholdofthedrivebelt.
5.Removethetapeandputthe”empty”endontothenipple.
6.Pressthedrive-beltendsrmlytowardseachothertosecurethenipple.
7.Pullthedrivebeltontothebeltpulleyandrotatetheexchangerbyhand.Checkthatthebeltpulley
rotates.
Note:
Ifthedrivebeltslips,thedrivebeltmaybetoolongandneedstobeshortened.Cutthedrivebelt5
mmandgotostep6.
8.Closeandlockthefronthatchandconnecttheunittomains.
9.CheckthatthealarmhasceasedontheControlDisplay.
Note:
Ifthealarmremains,checktherotorsensor.
