3Introduction
TheSAVEVTR200/Bisaheatrecoveryventilationunitwithabuiltinrotatinghighlyefcientheat
exchanger.TheSAVEVTR200/Bissuitableforsmalleratsorhouses.Itsupplieslteredoutdoorairto
residentialareasandextractairfrombathroom,kitchenandwetrooms.
Therearetwomodeloptions,right(R)andleft(L)model.Bothmodelscomewith500Wor1000W
installedre-heaterbattery.Thedifferentmodelsarerecognizedbytheplacingoftheinternalcomponents.
Thismanualdescribesbasicinformationhowtooperateandperformmaintenanceonaleft(L)unitand
thesystemitisconnectedto.
Note:
Thisdocumentdescribesaleft(L)model.Theinsideofaright(R)modelismirrored.
4Conguration
4.1Controlpanel
Connecttheunitelectricallytothemainswiththeenclosedplugandcheckthatitstartsupcorrectly.
Thecontrolpanelisusedtomakethenecessaryadjustments.
Anexternalcontrolpanelcanbeconnectedonthetopoftheunit.
Theillustrationbelowshowsthecontrolpanelwithashortdescription.
Fig.1Controlpanel
PositionDescriptionExplanation
1Display
Showssymbols,menusandsettings
2
SELECTIONknob
Movethroughthemenulistsorchangesettingsand
valuesbyturningtheknobleftorright
3ENTERbuttonENTERmenuchoicesorsettingsbypressingthebutton
4RETURNbutton
StepRETURNinthemenulevelsandtoabortaninitiated
parameterchangeandrestoretheoriginalvalueby
pressingthebutton
SAVEVTR200/BUserManual
208062
2
SystemairSverigeAB
