5.7.2Heatexchangerremoved
1.Stoptheunitbydisconnectingthemains.
2.Openthefronthatch.
3.Disconnecttheheatexchangerpowersupplyandtherotorsensor.Thecablesarefoundbesidethe
heatexchangerattheback.
4.Pullouttheheatexchangertowardsyou.Someforcemaybeneeded.
5.Removethebrokendrivebelt.
6.Applythenewdrivebeltaroundtheheatexchanger.
7.Pressthedrive-beltendsrmlytowardseachothertosecurethenipple.
8.Pullthedrivebeltontothebeltpulleyandrotatetheexchangerbyhand.Checkthatthebeltpulley
rotates.
Note:
Ifthedrivebeltslips,thedrivebeltmaybetoolongandneedstobeshortened.Cutthedrivebelt5
mmandgotostep7.
9.Mounttheheatexchanger.Don’tforgettoreconnecttherotorpowerandsensorcables.
10.Closethefronthatchandconnecttheunittomains.
11.CheckthatthealarmhasceasedontheControlDisplay.
Note:
Ifthealarmremains,checktherotorsensor.
6Overheatprotectionresetbutton
Ifthesupplyairtemperatureislow,itcanindicatethattheoverheatprotectionistriggered.Theoverheat
protectioncanberesetbypressingtheresetbutton(1).
Fig.5Overheatprotectionresetbutton
SAVEVTR200/BUserManual
208062
