4.1.1Displaysymbols
Symbol
DescriptionExplanation
Temp
Illustratesthecurrentset-pointforsupplyairtemperature
(fromcompletelyemptytolledsymbol).
TurntheSELECTIONknobtochoosetemperature.
PressENTERtosavethesetting.
AirowIllustratesthecurrentairow.Theairowcanbeset
manuallyin5steps:Off,Low,Nom,HighandAuto.
TurntheSELECTIONknobtochooseairow.
PressENTERtosavethesetting.
A.Ventilationoff.
1
B.Lowventilation:Canbeusedwhenleavingthe
buildingforalongerperiod
C.Nominalventilation:Willgiverequiredairchange
undernormalconditions.
D.Maximumventilation:T oincreasetheairowif
necessary.
E.Autoventilation:Willregulateafterthepre-settingfor
thedemandcontrolsettings.
Service
PressENTERtoaccesstheservicemenu.
AlarmPressENTERtoaccessthealarmlist.
1.ThefancanbesettoOFFbyactivatingmanualfanstop.Seeservicemenudescriptionunderfunctions.
Important
Itisnotrecommendedtoactivatemanualfanstop(setfantoOFF)instandardhouseholds.Ifmanualfan
stopisactivated,theunitshouldbeprovidedwithdampersinexhaustandfreshairductstoavoidcold
draughtandriskofcondensationwhentheunithasbeenstopped.
4.2Settingthetemperature
Thesupplyairtemperatureissetmanuallyinstepsof1Kinthemainmenudisplaybychoosingthe
temperaturesymbol.
Ifanelectricalre-heaterisinstalledthetemperaturesetpointsare:
12-22°C.Forinstalledwaterre-heaterthesetpointsare:12-40°C.
SAVEVTR200/BUserManual
208062
3
SystemairSverigeAB
