Mainmenuitem
Sub-menuitem1Sub-menuitem2
Explanations
Pressure
controlEAF
Setp1/1:250
Pa
Setp1/2:100
Pa
Settheexternalpressureset
pointfornormalspeed(1/1)
andreducedspeed(1/2)forthe
supplyairfan.
Outdoor
comp.Setp.1
—20°C=0Pa
10°C=0Pa
Act.Comp:0
Pa
SettheEAFpressure
compensationforthesettable
outdoortemperature.The
outdoorcompensationislinear
andissetusingtwoparameter
pairswhichgivethevalueofthe
compensationattwodifferent
outdoortemperatures.The
compensationcanbepositive
ornegative.
Showstheactualpressure
compensation.
→Timesettings
→Time/Date
Setcorrecttimeanddate.
→Timernormal
speed
SetweekscheduleMondayto
Sunday+Holidayfornormal
speed.Possibletoset2periods
perday.
00:0024:00forcontinuous
running.00:0000:00
inactivatestheperiod.
Notethesettingsinthe
commissioningrecord
→Timerreduced
speed
SetweekscheduleMondayto
Sunday+Holidayforreduced
speed.Possibletoset2periods
perday.
00:0024:00forcontinuous
running.00:0000:00
inactivatestheperiod.
Notethesettingsinthe
commissioningrecord
→Extended
running
Extended
running
60min
Timeinext.
running
0min
Setthetimeforextended
running.Digitalinputscanbe
usedtoforcetheunittostart
orincreasetoNormalrunning
althoughthetimersaysthe
runningmodeshouldbeOffor
Reduced.
Iftherunningtimeissetto0
theunitonlyrunsaslongasthe
digitalinputisclosed.
Thetimetheextendedrunning
isactiveismonitoredin"Time
inext.Running".
It'salsopossibletosetatime
hereaswellinordertoshorten
theinitialsetperiod.
TopvexSR09,11,TR09-15OperationandMaintenanceInstructions
207880
14
SystemairAB
