Page 57
English
Technical data
VLR 524 604 704 804
Power supply V/ph/Hz 400 (±10%) / 3 / 50
Number of circuits 2 2 2 2
Capacity steps % 25-50-75-100 28-57-78-100 20-50-70-100 25-50-75-100
Refrigerant
Type / GWP R410A / 2.088
Charge 1/2
(1)
kg 7,8/7,8 8,2/8,2 15/15 15/15
tCO
2
eq 16,3/16,3 17,1/17,1 31,3/31,3 31,3/31,3
Compressor
Type Scroll
Number 4 4 4 4
Start-up type Direct
N°of loading stages 0/100 0/100 0/100 0/100
Evaporator
Type Plate
Number 1 1 1 1
Water flow rate l/s 6,5 7,4 8,5 9,5
Pressure drop kPa 28,3 36,1 47,5 49,1
Water volume l 11,5 11,5 11,5 13,3
Hydraulic connections
Type Threaded Gas Male
Inlet diameter inch 2”1/2 2”1/2 2”1/2 2”1/2
Outlet diameter inch 2”1/2 2”1/2 2”1/2 2”1/2
Recovery condenser
Type Plate
Number 1 1 1 1
Water flow rate l/s 8,2 9,1 10,6 12,0
Pressure drop kPa 44,6 55,3 75,3 78,5
Water volume l 11,5 11,5 11,5 13,3
Hydraulic connections
Type Threaded Gas Male
Inlet diameter inch 2”1/2 2”1/2 2”1/2 2”1/2
Outlet diameter inch 2”1/2 2”1/2 2”1/2 2”1/2
Weights
Shipping weight kg 1184 1402 1576 1717
Operating weight kg 1208 1426 1600 1745
Additional Weights
ELN versions kg 30 35 35 35
HSE*/HPF** versions kg 30 30 30 30
Dimensions
Length mm 3300 3300 4300 4300
Width mm 1100 1100 1100 1100
Height mm 2300 2300 2300 2300
(1) The refrigerant value are indicative values for standard units. The actual data are indicated on the unit label.
(*) High Efficiency Units (HSE) with inverter fans.
(**) HPF Units with high static pressure fans.
