SystemAir VLS Series

Page 71
English
1044
2200 396396
3300
934
682
313
183
375
1761 LIFT
3 FANS size 604
2 FANS size 524
A
D
C
B
1179 LIFT
1100
2300
1249
WATER CONNECTIONS
WATER OUTLET “A” 2” 1/2 M
WATER OUTLET (recover) “B” 2” 1/2 M
WATER INLET “C” 2” 1/2 M
WATER INLET (recover) “D” 2” 1/2 M
Technical data
VLR 524-604 BLN/LN/ELN/HT
