7 Specification
Number of audio channels: 8 (4 x Stereo)
Number of audio inputs: 4 Stereo.
Audio loop out frequency response: 20Hz-20kHz +/- 0.8dB into 22k Ohms.
Audio loop out distortion: THD+N <0.005% 20hz-30kHz bandwidth.
Audio loop out level: -0.14dB lower than Input level.
Pre-Amplifier Output
Fixed & variable level output: frequency response 20Hz-20kHz +/- 0.8dB
Fixed level output distortion: THD+N 0.005% @1kHz
Variable level output distortion: THD+N 0.01% @1kHz
Power Amplifier Output
Frequency response: 20Hz-20kHz +/- 1dB
Distortion: THD+N 0.07% into 5 Ohms @ 13W
Output power per channel: 23W into 5 Ohms @ <0.4% THD+N
Dimensions: 430mm (w) x 360mm (d) x 98mm (h)
Weight: 9.8kg
Max Power Consumption: 430Watts
QED Audio Products Ltd. reserves the right to alter the specifications of the
products described in this manual at any time and without prior notice.
Section 7 • Specification
38
