Fine Tune Mode (Continued)
Symbol Description Used
In
Default Range User
Setting
Sv
d
Set Day Room Temperature
Origin (Only used when a space
temperature sensor is fitted) The
space temperature will influence the
compensated flow temperature for
each °C error from this figure.
Subject to the fine tune setting (INF)
*or
If the ING setting = 3 then this
setting is the primary base return
water origin relative to an outside
air temperature of 10°C.
Fine
Tune
Mode
19 *or
45
0 to 255°C
Valve or Boiler Control
Selects the controller type.
Fine
Tune
Mode
00 = Valve
1 = Boiler
Sv
n
Set Night Room Temperature
Origin (Only used when a space
temperature sensor is fitted) The
space temperature will influence the
compensated flow temperature for
each °C error from this figure.
Subject to the fine tune setting (INF)
*or
If the INF setting = 3 then this
setting sets the Max. Return Low
Limit.
Fine
Tune
Mode
16
0 to 255°C
Stroke Set Actuator Stroke Time in
Seconds
In order for the control loop to
operate accurately, the stroke time
for the actuator to run from Closed
to Open must be entered.
Fine
Tune
Mode
120 0–999
Seconds
Mr Maximum Return set Value Ratio
- (CSC 5252 only) If the INF setting
= 3 (Max. Return Application) this
value sets the set point ratio. The
outside air origin is 10°C. A divisor
of 100 is used for the Max. Return
Ratio setting, e.g. 83 = 0.83.
Fine
Tune
Mode
83 –10 to 127
CSC USER GUIDE October, 03
39 of 42
