22 (36), 0-004-7506-4 (EN) TAC AB, 2001-08-08
TAC Xenta OP Handbook 3 Dialogs with TAC Xenta 100
Input variables appear further down in the list:
Example: Select NV 013 to get the Application Mode:
13 nviApplicMode
Auto _
nvi indicates that this is an input value. The cursor is visible and
allows the value to be changed from the OP.
Use
+
and
–
to change the value. Keep the key pressed to
increase the toggling speed.
Press
to enter the new value.
If
or or is pressed before , no change will
take place.
The keys
and will take you to the adjoining NVs in the
list.
3.5 Initiate Service pin message
When the NV index selection is displayed
units as SI [^]
NV index? 000
a Service pin message is sent from the Xenta 100, initiated from the
OP, each time the
key is pressed.
