Air Chiller System (ACS) and Chiller Panel Getting Started Guide for the DMA 850 Page 24

4 Use the (4) locknuts to secure the panel to the ACS. Then use an appropriate length of tubing (supplied)

and connect the panel Outlet to the ACS Inlet.

Figure 13 Secure the panel to the ACS and connect to ACS Inlet.

ACS Inlet

Panel Outlet

Tubing

(4) Locknuts
