Discovery TGA™ Getting Started Guide Page 31
Connecting the Discovery TGA to the Controller
To connect the TGA system, you will need access to the Discovery TGA instrument’s back panel.
NOTE: Connect all cables before connecting the power cord to an outlet.
CAUTION: Whenever plugging or unplugging power cords, handle them by the plugs, not by the
cords.
MISE EN GARDE: Chaque fois que vous branchez ou débranchez les cordons d'alimentation,
tenez-les par les fiches et non par les cordons.
The Discovery TGA back panel has fifteen ports; the table below provides a description of the function of
each port.
WARNING: Protect power and communications cable paths. Do not create tripping hazards by
laying the cables across access ways.
AVERTISSEMENT: Protégez les chemins de câble électriques et de câbles de télécommunica-
tion. Ne créez pas de risques de déclenchement en posant des câbles sur les voies d'accès.
Table 6: Discovery TGA Back Panel
Port Function
Power Entry Module (power cord and switch) Provides power and protective earthing to the system.
Fuses Provides overcurrent protection.
REACTIVE GAS Port for introducing an additional gas directly into the
vicinity of the sample and reference. External flow regulation
required. Maximum pressure is 140 kPa gauge (20 psig).
GAS 1 Gas inlet port controlled by the gas delivery module. Used for
the sample and balance purge gas. Maximum pressure is
140 kPa gauge (20 psig).
GAS 2 Gas inlet port controlled by the gas delivery module. Used for
the secondary sample purge gas. Maximum pressure is
140 kPa gauge (20 psig).
COOLING GAS Provides the furnace with air for post-run cooling. Maximum
pressure is 140 kPa gauge (20 psig).
RS-232 Port Provides communications with external accessories.
CAN Communications Port Provides communications with external accessories.
Ethernet Provides communication between controller and TGA
instrument.
USB 2.0 Port Provides communications with external accessories.
Micro USB 2.0 Port Provides communications for external accessories.
SD memory card slot For TA Instruments Service use only.
