TA-CMI Measure Valve
19
Measure Valve TA-CMI
18
Entering the valve factor (Kv value) for other valve types
This section applies only to non TA valves.
1. Select valve type “Other”.
2. Confirm. 8. Enter a suitable valve name by using the up,
down and right keys.
3. Open the Valve factor dialog by pressing the
down key, then pressing Enter.
9. Confirm the entered valve name.
4. Enter the appropriate valve factor, by using
the up and down keys. Use the right key to
move the cursor to the next digit.
5. Confirm.
10. After you have entered the appropriate valve
factor (and perhaps valve name) press Done.
Then continue with step 12 on page 16.
If you want to enter a name for the valve (optional), do this according to steps 6 – 9. Otherwise
go directly to step 10.
6. To enter a name for the valve, select
Functions.
7. Then select Add Valve.
