TMA Q Series Getting Started Guide
32
Ethernet Connection
Yellow Light
Green Light
Connecting the Controller to a LAN
Before you can connect the controller to a LAN, you will need to have
already installed a network interface card into the computer.
1. Locate the second Ethernet port on the back of the computer.
2. Plug one end of the Ethernet cable into the computer's Ethernet port.
3. Plug the other end into the LAN.
4. Check the Ethernet port on the rear of the computer. If communication
between the computer and the LAN has been properly established, a
solid green light and flashing yellow light will appear at the port.
