Customer Service Toll Free: 833.3TACTILE (833.382.2845)
If you have questions or to obtain warranty service, contact:
Tactile Medical
Product Support Department
833.3TACTILE (833.382.2845), ext. 4300
7 a.m. to 7 p.m. CT, Monday–Friday
10.3 Limited Warranty and Service for Facility Use
Contact Tactile Medical for information regarding the service
agreements available to facilities.
10.4 Equipment Lifetime
When used and maintained as instructed, the average expected
controller unit lifetime is ve (5) years.
10.5 Return Policy
Tactile Medical does not accept returns or provide refunds for any
medical equipment dispensed to patients, including garments/
sleeves, controller unit or any accessories once the original packaging
has been opened. Unopened equipment may be returned within
sixty (60) days of the date of shipment.
10.6 Patents
Patents pending.
Table 3: Flexitouch Plus System—Technical Information
Model Number PD32–G3
Power Adapter Input 100–240 VAC 50/60 Hz
Device Input Voltage 12 VDC Nominal
Device Input Current 3.0 A Maximum
Current 1.0 A Maximum
Controller Unit Size 8”H x 10”W x 8”D (203 mm x 254 mm x 203 mm)
Controller Unit Weight 6.2 lbs. (2.8 kg)
Outer Fabric 100% nylon, not made with natural rubber latex
Treatment Programs 18
Chambers (max) 32
Mode of Operation Continuous
Calibration
Recalibration not required for the
Flexitouch Plus system
Electromagnetic
Interference (EMI)
Electromagnetic
Compatibility (EMC)
The Flexitouch Plus system was designed to
minimize the eects of external EMI upon the device
and to minimize the eect upon the environment
from the device. The device conforms to the
appropriate EMC standards. See Table 5 on page 125.
Operating
Atmospheric Pressure
700 to 1060 hPa
10.7 Technical Information
The Flexitouch Plus system has the following characteristics:
Device Transport
and Storage
Temperature Limits
-40
°
C
-40
°
F
Device Operating
Temperature Limits
Device Transport
and Storage
Humidity Limits
Device Operating
Humidity Limits
