8. Operation
levels
8.1
Levels
diagram
8.2 Lock
function
T
o use lock function, please se
t p
arameter “LCK” in level 2.
Levels entering available
LCK
Level 1
(User)
Level 2
(PID)
Level 3
(Input)
Level 4
(SET)
Parameters which can be
changed
◎
◎
◎
------
All
parameters
(Factory set value)
◎
◎
------
◎
All
parameters
◎
◎
------
------
All parameters except level 3
◎
◎
------
------
Parameters in level 1
◎
◎
------
------
“SV” and “LCK”
◎
◎
------
------
Only
“LCK”
24
26
