16.3 3ϕ Zero Cross Control (SCR module)
OUT1 : 3Φ SCR zero cross control
Parameter setting : OUTY= 0, CYT1= 1
Wiring Setup :
R S T
Fast Fuse
RK1 TK1
SCR
RG1 TG1
Module
RG2 TG2
RK2
TK2
U V W
three phase three wire system
Time Chart：
OFF
ON
CYCLE TIME = 200ms
16.4 3ϕ Zero Cross Control (TRIAC module)
OUT1 : 3Φ SCR zero cross control
Parameter setting : OUTY= 0, CYT1= 1
Wiring Setup :
R S T
Fast Fuse
T2 (RG2) T2 (TG2)
G (RG1) G (TG1)
1T 1T
U V W
three phase three wire system
Controller
RG1
RK1
RG2
RK2
TG1
TK1
TG2
TK2
Controller
RG1
RK1
RG2
RK2
TG1
TK1
TG2
TK2
