Taie FU48 - LEVEL_4 Parameter

10.9 LEVEL_3 Parameter
tnetnoC lobmyS retemaraP
Range
Default
Hide/
MAX MIN
Display
SETA
Alarm special function setting
1111 0000 0000 SET5.3
(Please refer to Chapter 12.2)
Protocol selection
PSL
0 : TAIE
RTU
TAIE RTU SET5.4
1 : RTU
(Please refer to communication manual)
Data format
0 : O_81
(parity bit=odd, stop bit=1)
1 : O_82
(parity bit=odd, stop bit=2)
BITS
2 : E_81
(parity bit=even, stop bit=1) N_82 O_81 O_81 SET5.4
3 : E_82
(parity bit=even, stop bit=2)
4 : N_81
(parity bit=none, stop bit=1)
5 : N_82
(parity bit=none, stop bit=2)
IDNO Controller station 254 0 1 SET5.4
Baud rate
0 : 24(2400)
1 : 48(4800)
BAUD
2 : 96(9600)
1152 24 384 SET5.4
3 : 192(19200)
4 : 384(38400)
5 : 576(57600)
6 : 1152(115200) bps
SVOS SV bias 100.0 -100.0 0 SET6.1
PVOS
PV bias
100.0 -100.0 0 SET6.2
PV = PV + PVOS
Unit
Change this parameter USPL&LSPL
UNIT
will be reset
2 0
--- SET6.3
0 : °C
1 : °F
2 : U (Linear signal)
PV digital filter
PVFT
The PV filter is used to eliminate noise
5.00 0.01 0.10 SET6.4
against the measured input
Unit : second
PV2 Use for motor valve feedback value --- --- --- SET7.1
OUD
Control action selection
LOOC noitca esrever TAEH : 0 HEAT HEAT SET7.2
1 : COOL direct action
OPAD
Super SV function enable
0 : OFF ON OFF ON SET7.3
1 : ON
HZ
Power frequency
0 : 50HZ 50HZ 60HZ 60HZ SET7.4
1 : 60HZ
27 FY/FU operation manual
