Task 10 —
Repair Output
Matching Circuitry
If the checks in Task 9 show that the power and current are still skewed,
there is a fault in the output matching circuitry.
1. If not already done, remove the
PAF TOP can.
2. Check for faulty, shorted or misplaced components in the circuit
between the test capacitor and the common drain of Q309 and Q310
(see Figure 14.8 and Figure 14.9). Repair any fault.
3. Program the radio with the highest
frequency in the radio’s frequency
band: Enter the CCTM command 101 x x 0, where x is the frequency
in hertz.
4. Enter the CCTM command 33 to place the radio in transmit mode.
5. Note the RF output power measured by the test set, and note the
current reading on the DC power supply.
6. Enter the CCTM command 32 to place the radio in receive mode.
7. Program the radio with the centre
frequency in the band: Enter the
CCTM command 101 x x 0, where x is the frequency in hertz.
8. Repeat Step 4 to Step 6.
9. Program the radio with the lowest
frequency in the band: Enter the
CCTM command 101 x x 0, where x is the frequency in hertz.
10. Repeat Step 4 to Step 6.
11. Remove the test lead and test capacitor, and resolder the coupling
capacitors C348, C349 and C350 in position (see Figure 14.8 and
Figure 14.9).
12. If the power and current are now correct at all three frequencies, the
fault has been rectified; go to “Final Tasks” on page 123. If they are
not, go to Task 26
in “RF Signal Path” on page 321.
RF output power: > 70W (VHF), > 60W (UHD)
current: < 15A (VHF), < 12A (UHF)
