352 CODEC and Audio Fault Finding TB7100 Service Manual
© Tait Electronics Limited October 2005
Figure 15.4 Circuitry under the
CDC BOT can
LO2 BOT CAN
CAN FOR
DIGITAL
BOARD
JUNCTION OF R218 AND IC204CDC AUD TAP OUT
