Tait TB9100 Service Manual

106 Appendices TB9100 Reciter Service Manual
© Tait Electronics Limited January 2006
8.2.3 J102 ASIF DSP to Reciter DSP Connector
Table 8.4 ASIF DSP to Reciter DSP Connector Pinout
Pin Number Signal Name Direction Function
1 Not used
2GND
3 Not used
4GND
5 Not used
6GND
7 Not used
8GND
9 DSP_DT2 I/P DSP receive data
10 GND
11 DSP_TCLD2 I/P DSP receive clock
12 GND
13 DSP_TFS2 I/P DSP receive frame sync
14 GND
15 DSP_DR2 O/P DSP transmit data
16 GND
17 DSP_RCLK2 I/P DSP transmit clock
18 GND
19 DSP_RSF2 I/P DSP transmit frame sync
10 GND
21 DSP_SIF_INT O/P 1 PPS interrupt
