TB9100 Reciter Service Manual Appendices 111
© Tait Electronics Limited January 2006
8.4 Appendix D – Processor Port Assignments
8.4.1 MPC859T Port Assignments
Note Many of the pins on the MPC859T have multiple functions.
Where a particular pin function is used in the ASIF application,
this is indicated in bold text; unused functions or unused pins are
in plain text. This table is sorted by pin name order; where a pin
has multiple function names, these are listed in the order shown
on the schematic. This table also lists the UTOPIA interface pin
names, but, for clarity, these are not shown on the schematic.
Table 8.10 MPC859T Port Assignments
Pin Name Pin No. Type Function
A[0] B19 I/O Address bus 0 - msb
A[1] B18 I/O Address bus 1
A[2] A18 I/O Address bus 2
A[3] C16 I/O Address bus 3
A[4] B17 I/O Address bus 4
A[5] A17 I/O Address bus 5
A[6] B16 I/O Address bus 6
A[7] A16 I/O Address bus 7
A[8] D15 I/O Address bus 8
A[9] C15 I/O Address bus 9
A[10] B15 I/O Address bus10
A[11] A15 I/O Address bus 11
A[12] C14 I/O Address bus 12
A[13] B14 I/O Address bus 13
A[14] A14 I/O Address bus 14
A[15] D12 I/O Address bus 15
A[16] C13 I/O Address bus 16
A[17] B13 I/O Address bus 17
A[18] D9 I/O Address bus 18
A[19] D11 I/O Address bus 19
A[20] C12 I/O Address bus 20
A[21] B12 I/O Address bus 21
A[22] B10 I/O Address bus 22
A[23] B11 I/O Address bus 23
