TB9100 Reciter Service Manual Appendices 125
© Tait Electronics Limited January 2006
HA[0] D16 I/P Host address bus 0
HA[1]/HCNTL1 E16 I/P Host address bus 1
HA[2]/HAS F15 I/P Host address bus 2
HA[3] G15 I/P Host address bus 3
HA[4] H14 I/P Host address bus 4
HA[5] J14 I/P Host address bus 5
HA[6] K17 I/P Host address bus 6
HA[7] J16 I/P Host address bus 7
HA[8] G14 I/P Host address bus 8
HA[9] F14 I/P Host address bus 9
HA[10] E15 I/P Host address bus 10
HA[11] D15 I/P Host address bus 11
HA[12] E14 I/P Host address bus 12
HA[13] G17 I/P Host address bus 13
HA[14] H16 I/P Host address bus 14
HA[15] J15 I/P Host address bus 15
HA[16] K16 I/P Host address bus 16
HA[17] M15 I/P Host address bus 17
HA[18] M14 I/P Host address bus 18
HA[19] N17 I/P Host address bus 19
HBE0 K15 I/P HPI byte enable 0
HBE1 M16 I/P HPI byte enable 1
HCNTL0 N15 I/P Host control register select
HCS C16 I/P Host chip select
HD[0] B16 I/O Host data bus 0
HD[1] B13 I/O Host data bus 1
HD[2] B11 I/O Host data bus 2
HD[3] B15 I/O Host data bus 3
HD[4] C9 I/O Host data bus 4
HD[5] C10 I/O Host data bus 5
HD[6] C11 I/O Host data bus 6
HD[7] C12 I/O Host data bus 7
HD[8] C13 I/O Host data bus 8
Table 8.11 TMS320VC5510 Port Assignments (Continued)
Pin Name Pin No. Type Function
