TM8100/TM8200 Service Manual Frequency Synthesizer Fault Finding 187
© Tait Electronics Limited June 2006
Task 4 —
6V Power Supply
If the output of the SMPS is correct, check the 6V DC supply next.
1. Measure the supply +6
V0 at pin 4 of IC606 (see Figure 9.2).
2. If the voltage is correct, go to Tas k 5
. If it is not, measure the 9V
input at pin 5 of IC606 (see Figure 9.2).
3. If the voltage is correct, go to Step 4. If it is not, the 9V regulator
IC601 is suspect; go to Tas k 3
of “Power Supply Fault Finding” on
page 168.
4. If the input to the regulator IC606 is correct but not the output,
check IC606 (see Figure 9.2) and the associated circuitry; if
necessary, replace IC606.
Remove the
SYN TOP can and check the C-multipliers Q508 (pins 3,
4, 5) and Q512 for shorts (see Figure 9.2); replace any suspect
transistor.
5. If a fault is found, repair the circuit, confirm the removal of the fault,
and go to “Final Tasks” on page 157. If the repair failed or no fault
could be found, replace the board and go to “Final Tasks” on
page 157.
pin 4 of IC606: 6.0 ± 0.3V DC
pin 5 of IC606: 9.0 ± 0.3V DC
